Collagen Overview:
Collagen is a biopolymer, the main component in animal connective tissue, and the most abundant and widely distributed functional protein in mammals, accounting for 25% to 30% of total protein, and some organisms even up to 80%. .
Animal-derived animal tissue is the main way for people to obtain natural collagen and its collagen peptides. However, due to related animal diseases and certain religious beliefs, the use of collagen and its products in terrestrial mammals has been restricted. Developed in biology. The European Food Safety Authority (EFSA) has confirmed that even collagen-derived collagen does not have the potential to infect mad cow disease and other related diseases.
Due to differences in amino acid composition and degree of cross-linking, the rich collagen contained in aquatic animals, especially their processing waste, skin, bone and scale, has many advantages that are not found in livestock collagen, and is also derived from marine animals. Collagen is superior in some respects to terrestrial animal collagen, such as low antigenicity, hypoallergenic and other characteristics. Therefore, aquatic collagen may gradually replace terrestrial animal collagen.

JYPG Collagen Spray Dryer Product Introduction
Spray drying is a widely used process in the liquid process forming and drying industries. It is especially suitable for the production of powdery, granular solid products from solutions, emulsions, suspensions and paste liquids. Therefore, spray drying is an ideal process when the particle size distribution, residual moisture content, bulk density and particle shape of the finished product must meet exact standards.

JYPG collagen spray dryer works
The air is filtered and heated to enter the air distributor at the top of the dryer, and the hot air enters the drying chamber in a spiral shape evenly. The liquid is sprayed into a very fine misty liquid droplet through a high-speed centrifugal atomizer at the top of the tower body, and it can be dried into a finished product in a short time by cocurrent contact with hot air. The finished product is continuously discharged from the bottom of the drying tower and the cyclone, and the exhaust gas is vented by the fan.

JYPG collagen spray dryer performance characteristics
◎The drying speed is fast, the surface area of the liquid is greatly increased after atomization. In the hot air flow, 95%-98% of the water can be evaporated in an instant, and the drying time is only a few seconds, which is especially suitable for the drying of heat sensitive materials.
◎The product has good uniformity, fluidity and solubility, and the product has high purity and good quality.
◎ Simplified production process and convenient operation and control. For liquids with a moisture content of 40-60% (up to 90% of special materials), the products can be dried into powdered products at one time. After drying, no pulverization and screening are required, which reduces the production process and improves the purity of the products. The particle size, bulk density and moisture of the product can be adjusted within a certain range by changing the operating conditions, and the control and management are very convenient.

Our company independently develops and manufactures a special dryer for collagen based on the performance characteristics of collagen. You are welcome to inquire for detailed technology!

•
  JYPG collagen spray dryer
•
  JYPG collagen spray dryer
•
  JYPG collagen spray dryer
•
  JYPG collagen spray dryer
•
  JYPG collagen spray dryer
