First, LG precision dry granulator equipment overview:
The dry granulator is a device that directly processes materials from powder to granules without adding water, mixing, granulation, drying, etc., according to the way of conveying, the dry granulator can be divided into vertical conveying and There are two forms of horizontal conveying. The horizontal conveying dry granulator has advanced technology, stable performance and high granulation rate. The dry granulator produced by our company is horizontal conveying type.

Second, LG precision dry granulator equipment features:
Compared with other granulation equipment, LG precision dry granulator has the following characteristics:
1. Direct granulation of dry powder without any binder;
2. The material is mechanically extruded without destroying the chemical properties of the material and does not reduce the effective content of the product;
3, the pressure wheel is arranged up and down, eliminating the influence of gravity on the material, and ensuring the uniformity of the material before tableting;
4. The gap of the pressure roller is adjustable, so that the density of the tablet is uniform and the granulation is uniform;
5, low energy consumption, small footprint;
6. High granulation rate and high production efficiency;
7. With hydraulic system, the hardness and density of the particles can be adjusted;
8, the device structure is simple, easy to disassemble and clean;
9. Equipped with a vacuum device to make the tablet more dense and the granulation rate is high;
10. With three kinds of grain pressure rollers, net grain, straight grain and smooth surface, match different characteristics of materials;
11. The control system has a memory built in it, which can store 10 million sets of production data;
12, the equipment is controlled by PLC, the man-machine interface is beautiful and simple, easy to operate, easy to learn.

Third, LG precision dry granulator equipment structure:
LG Precision Series Dry Granulator is a technologically advanced, economical and environmentally friendly product developed by our company. It occupies less space, is energy-saving and environmentally friendly, and is easy to disassemble and clean. It is an ideal production equipment for large-scale granulation. It consists of the following parts: feeding system; deceleration and change direction system; conveying device; extrusion system; sizing system; front cover; frame; inspection door; control system; hydraulic system; pneumatic system; water cooling system; And other devices.

•
  LG precision dry granulator
•
  LG precision dry granulator
