GHL wet granulator

Key word：GHL series high speed mixing granulator, high speed mixing granulator, mixing granulator

Product overview：The powder material and the binder are thoroughly mixed into a wet soft material from the bottom mixed slurry in a cylindrical container, and then cut into uniform wet particles by a side-mounted high-speed pulverizing paddle...

Details Photo gallery Video

working principle
The powder material and the binder are thoroughly mixed into a wet soft material from the bottom mixed slurry in a cylindrical container, and then cut into uniform wet particles by a side-mounted high-speed pulverizing paddle.
Performance characteristics
◎ This machine adopts horizontal cylinder structure and has reasonable structure.
◎Inflatable sealed drive shaft can be switched to water during cleaning.
◎ Fluidized granulation, granulated approximately spherical, and good fluidity.
◎ 25% less adhesive than traditional process, shortening drying time.
◎ Each batch is only dry mixed for 2 minutes, granulation for 1-4 minutes, and the work efficiency is 4-5 times higher than the traditional process.
◎ Completed in the same closed container, dry mixing-wet mixing-granulation, and the process is shortened.
◎The whole operation has strict safety protection measures.
◎ can be made into a jacket type according to user requirements.
Technical specifications

model	A	B	C×D	E	F
50	320	950	1250×800	970	1650
150	420	1000	1350×800	1050	1750
200	500	1100	1650×940	1450	2050
250	500	1160	1650×940	1400	2260
300	550	1200	1700×1000	1400	2310
400	670	1300	1860×1100	1550	2410
600	750	1500	2000×1230	1750	2610

name	型号
name	50	150	200	250	300	400	600
Volume L	50	150	200	250	300	400	600
Yield kg/batch	15	50	80	100	130	200	280
Mixing speed r.p.m	200/400	180/270	180/270	180/270	140/220	106/155	80/120
Mixed power kw	4/5.5	6.5/8	9/11	9/11	13/16	18.5/22	22/30
Cutting speed r.p.m	1500/3000	1500/3000	1500/3000	1500/3000	1500/3000	1500/3000	1500/3000
Cutting power kw	1.3/1.8	2.4/3	4.5/5.5	4.5/5.5	4.5/5.5	6.5/8	9/11
Compressed air consumption m3/min	0.6	0.9	0.9	0.9	1.1	1.5	1.8
weight kg	500	800	1000	1300	1800	2200	2600
