CT/CT-C hot air circulation oven
product description
CT-C series hot air circulation oven is equipped with low noise and high temperature axial flow fan and automatic temperature control system. The whole circulation system is completely enclosed, which improves the thermal efficiency of the oven from 3-7% of the traditional drying room to the current 35-45%. The thermal efficiency can reach 50%. It has saved a lot of energy for China and improved the economic benefits of the company. In 1990, the National Pharmaceutical Administration issued an industry standard, the unified model is RXH.
Schematic
◎The heating heat source has steam, electricity, far infrared and electric steam for users to choose;
◎ use temperature: steam heating 50 ~ 140oC, up to 150oC;
◎ electricity, far infrared temperature 50 ~ 350oC;
◎ equipped with automatic control system and computer control system for users to choose;
◎ Commonly used steam pressure 0.02-0.8Mpa (0.2~8kg/m2);
◎With electric heating, calculate 15KW according to type I, practical 5-8kw/h;
◎Special requirements are stated when ordering;
◎ Non-standard oven price is negotiable;
◎Use temperature greater than 140oC or less than 60oC, please indicate when ordering;
◎The factory drying and baking trays are uniform in size and can be exchanged;
◎ Baking tray size: 460 × 640 × 45 (mm).
Performance characteristics
Most of the hot air circulates in the tank, which is highly efficient and saves energy. The utility model utilizes the forced ventilation function, and the adjustable air distribution plate is arranged in the box, the material is evenly dried, and the heat source can be selected from steam, hot water, electricity and far infrared. The whole machine has low noise and balanced operation. Temperature control, easy installation and maintenance. Wide range of applications, can dry a variety of materials, is a general drying equipment.
schematic diagram
Technical specifications
Industry standard model |
Technical Parameters Model specification |
Dry amount per time (kg) |
Matching power (kw) |
Consumption of steam (kg/h) |
Cooling area (m2) |
Air volume (m3/h) |
Upper and lower temperature difference (oC) |
With baking tray |
Dimensions Face width × depth × height |
Supporting drying car | equipment weight |
RXH-14-B | CT-Ⅰ | 120 | 1.1 | 20 | 20 | 2800 | ±2 | 48 | 2430×1200×2375 | 2 | 1200 |
RXH-27-B | CT-Ⅱ | 240 | 2.2 | 40 | 40 | 5200 | ±2 | 96 | 2430×2200×2433 | 4 | 1500 |
RXH-41-B | CT-Ⅲ | 360 | 3 | 60 | 80 | 8000 | ±2 | 144 | 3430×2200×2620 | 6 | 2000 |
RXH-54-B | CT-Ⅳ | 480 | 4 | 80 | 100 | 9800 | ±2 | 192 | 4460×2200×2620 | 8 | 2300 |
RXH-5-C | CT-C-O | 25 | 0.45 | 5 | 5 | 3450 | ±2 | 16 | 1130×1100×1750 | 0 | 800 |
RXH-7-C | CT-C-ⅠA | 50 | 0.45 | 10 | 10 | 3450 | ±2 | 24 | 1400×1200×2000 | 1 | 1000 |
RXH-14-C | CT-C-Ⅰ | 120 | 0.45 | 18 | 20 | 3450 | ±2 | 48 | 2300×1200×2000 | 2 | 1500 |
RXH-27-C | CT-C-Ⅱ | 240 | 0.9 | 36 | 40 | 6900 | ±2 | 96 | 2300×2200×2000 | 4 | 1800 |
RXH-27A-C | CT-C-ⅡA | 240 | 0.9 | 36 | 40 | 6900 | ±2 | 96 | 4460×1200×2290 | 4 | 1800 |
RXH-41-C | CT-C-Ⅲ | 360 | 1.35 | 54 | 80 | 10350 | ±2 | 144 | 3430×2200×2000 | 6 | 2200 |
RXH-42A-C | CT-C-ⅢA | 360 | 1.35 | 54 | 80 | 10350 | ±2 | 144 | 2300×3200×2000 | 6 | 2200 |
RXH-54-C | CT-C-Ⅳ | 480 | 1.8 | 72 | 100 | 13800 | ±2 | 192 | 4460×2200×2290 | 8 | 2800 |
RXH-25-A | Efficient high temperature far infrared sterilization oven Power matching according to temperature requirements | 1200×1000×1600 | 1 | 1200 |
Adaptable material
It is suitable for heat curing, drying and dehydration of materials and products in pharmaceutical, chemical, food, agricultural and sideline products, aquatic products, light industry, heavy industry and other industries. Such as raw materials, raw drugs, Chinese herbal medicine pieces, extracts, powders, granules, granules, water pills, packaging bottles, pigment dyes, dehydrated vegetables, dried melons, sausages, plastic resins, electrical components, baking varnish and so on.
